Specifications
Lightweight aluminium and honeycomb fiberglass floor construction
Build in strap hook ready
Extra narrow design ideal for indoor use
Aluminum diamond plate flooring
Front extra-duty bumper
Rear extra-duty bumper
Sliding rear window
Electric dump bed
Extended range battery packs
Extended life and range with lithium battery pack
Navigation
Telematics
Emergency caution light package
Law enforcement/ Security package
Sliding rear window
Extended rear step bumper ( +6 inches )
Front anti-sway bar kit
Trailer hitch kit ( class I )
Trailer light connector kit
Heavy duty trailer connector kit
110VAC 15A Power Source
High clearance kit ( 2+ inch added ground clearance)
12-volt Power Outlet
Dome light
Overhead console storage
Rubber floor mat
AM FM Bluetooth USB stereo
Hands Free Phone
Passenger vanity mirror
Seat with headrest
Cabin heater
Ignition key
Sun visors
Central locking system
Locking cabin doors
Windshield defroster
Cup holder
Back-up camera
Windshield wiper and washer
14 " alloy wheels
P175/65R14 all season tire
Folding rear view mirrors
Front tow hook
Halogen head lamp
LED brake,reverse & rear turn
Central door lock system
BASICS
Dimensions
145,5 in x 53.5 in x 75 in
3700mm x 1350mm x 1905mm
Payload Capacity 1
1100 lbs
500 kg
Cargo Volume 1
31,5 ft2
Bed capacity 2
2.93 m2
PERFORMANCE
Max Speed 2
25–35 mph based on local laws
40+ mph off-road
Range
Up to 50 mi at 25 mph standard
Turning Radius
157 in
4000 mm
Gradeability
30% unloaded and 20% loaded
Acceleration
0-20 mph under 6 s
0-30 km/h under 6 s
Braking Distance
25-0 mph in 25 feet
40-0 km/h in 7.5 m
DRIVE SYSTEM
Battery Type
Gel Lead Acid (Standard)
Operating Voltage
72 VDC
Motor Nominal Power
10 kW (13 hp)
Motor Peak Power
24 kW (32 hp)
Rear Wheel Peak Torque
1173 Nm (752 ft. lbs)
CHASSIS
Drive
2WD rear
Front Suspension
Transverse leaf spring
Rear Suspension
Torsion-beam suspension
Brake
Four wheel disc
Tire
175/65 R20
Bodywork
Reinforced ABS
Steering
Electrical power assist steering
110VAC 15A Power Source
"Rack-it " brand custom lumber rack
"Rack-it " brand multi piece lumber rack
Electric dump bed
Extended range battery packs
Extended life and range with lithium battery pack
Navigation
Telematics
Emergency caution light package
Exterior Work Lights
Law enforcement/ Security package
Sliding rear window
Front extra-duty bumper
Rear extra-duty bumper
Extended rear step bumper ( +6 inches )
Front anti-sway bar kit
Trailer hitch kit ( class I )
Trailer light connector kit
Heavy duty trailer connector kit
Additional options available
High clearance kit ( 2+ inch added ground clearance)
